package require Tktable # 5行5列のテーブル pack [table .t -variable ary -rows 5 -cols 5] # 配列の添え字の表示 for {set i 0} {$i < 5} {incr i} { for {set j 0} {$j < 5} {incr j} { set ary($i,$j) "ary($i,$j)" } } |
-variableオプションで配列変数を与えると、その配列変数を2次元配列のように使い各セルの値を格納します。
各セルと配列変数の添え字の関係を以下に示します。
この時の配列変数aryをダンプしてみると、以下の様になっています。
最後のary(active)は、アクティブなセル(キャレットがあるセル)がどこかを示します。
現在は、アクティブなセルがないので、空になっています。
% parray ary ary(0,0) = ary(0,0) ary(0,1) = ary(0,1) ary(0,2) = ary(0,2) ary(0,3) = ary(0,3) ary(0,4) = ary(0,4) ...途中省略... ary(4,0) = ary(4,0) ary(4,1) = ary(4,1) ary(4,2) = ary(4,2) ary(4,3) = ary(4,3) ary(4,4) = ary(4,4) ary(active) = |
次に、5行5列の表にタイトルとスクロールバーを付けてみます。
スクロールバーの付け方は、TkのWidgetの場合と同じです。
package require Tktable # 5行5列のテーブル table .t -variable ary -rows 5 -cols 5 \ -colstretchmode unset -rowstretchmode unset \ -multiline 0 -selectmode extended \ -titlerows 1 -titlecols 1 -selecttitle 1 \ -xscrollcommand {.x set} -yscrollcommand {.y set} scrollbar .x -command {.t xview} -orient horizontal scrollbar .y -command {.t yview} -orient vertical grid .t .y -sticky news grid .x -sticky news grid rowconfigure . 0 -weight 1 grid columnconfigure . 0 -weight 1 # タイトルの作成 .t tag config title -relief groove for {set i 0} {$i < 5} {incr i} { for {set j 0} {$j < 5} {incr j} { if {$i == 0 && $j > 0} { set ary($i,$j) [format %c [expr 64+$j]] } elseif {$j == 0 && $i > 0} { set ary($i,$j) $i } } } # colのサイズ設定 .t width 0 3 |
これで画面のリサイズにも追従しますし、タイトル部をクリックすると、
行または列ごとセレクトできます。
更に、セルや行/列ごとに色を付けることもできます。
-rowtagcommandと-coltagcommandオプションで色付けのコマンドを起動します。
package require Tktable # 5行5列のテーブル table .t -variable ary -rows 5 -cols 5 \ -colstretchmode unset -rowstretchmode unset \ -multiline 0 -selectmode extended \ -titlerows 1 -titlecols 1 -selecttitle 1 \ -xscrollcommand {.x set} -yscrollcommand {.y set} \ -rowtagcommand rowProc -coltagcommand colProc scrollbar .x -command {.t xview} -orient horizontal scrollbar .y -command {.t yview} -orient vertical grid .t .y -sticky news grid .x -sticky news grid rowconfigure . 0 -weight 1 grid columnconfigure . 0 -weight 1 # 奇数の行/列に色を設定 .t tag config OddRow -bg orange -fg purple .t tag config OddCol -bg brown -fg pink proc rowProc row { if {$row>0 && $row%2} { return OddRow } } proc colProc col { if {$col>0 && $col%2} { return OddCol } } # タイトルの作成 .t tag config title -relief groove for {set i 0} {$i < 5} {incr i} { for {set j 0} {$j < 5} {incr j} { if {$i == 0 && $j > 0} { set ary($i,$j) [format %c [expr 64+$j]] } elseif {$j == 0 && $i > 0} { set ary($i,$j) $i } } } # colのサイズ設定 .t width 0 3 |
package require Tktable # A+B=C proc change_cell {cell} { global ary set row [lindex [split $cell ,] 0] set col [lindex [split $cell ,] 1] if {$row == 0 || $col == 0} return set sum 0 for {set i 1} {$i < 3} {incr i} { catch "set sum [expr $sum + $ary($row,$i)]" } set ary($row,3) $sum } # 5行5列のテーブル table .t -variable ary -rows 5 -cols 5 \ -colstretchmode unset -rowstretchmode unset \ -multiline 0 -selectmode extended \ -titlerows 1 -titlecols 1 -selecttitle 1 \ -browsecommand {change_cell %s} \ -xscrollcommand {.x set} -yscrollcommand {.y set} scrollbar .x -command {.t xview} -orient horizontal scrollbar .y -command {.t yview} -orient vertical grid .t .y -sticky news grid .x -sticky news grid rowconfigure . 0 -weight 1 grid columnconfigure . 0 -weight 1 # Excel風のbindings bind Table <Tab> {::tk::table::MoveCell %W 0 1} bind Table <Return> {::tk::table::MoveCell %W 1 0} # セルのanchor .t tag config active -anchor w .t tag config e -anchor e # タイトルの作成 .t tag config title -relief groove -fg black -bg [.t cget -bg] .t tag config active -fg black for {set i 0} {$i < 5} {incr i} { for {set j 0} {$j < 5} {incr j} { if {$i == 0 && $j > 0} { set ary($i,$j) [format %c [expr 64+$j]] } elseif {$j == 0 && $i > 0} { set ary($i,$j) $i } else { .t tag cell e $i,$j } } } # colのサイズ設定 .t width 0 3 |
タグの機能を使って、値のセルは右寄せにして、アクティブのセルは左寄せにしてあります。
package require Tktable # 配列の値を取得 proc getary {cell} { global ary # 空のセルは0とみなす if {![info exists ary($cell)]} { return 0 } else { return $ary($cell) } } # 差引残高+収入-支出 proc change_cell {cell} { global ary set row [lindex [split $cell ,] 0] set col [lindex [split $cell ,] 1] if {$row == 0 || $col == 0} return while {[info exists ary($row,1)]} { set in [getary $row,4] set out [getary $row,5] if {$row == 1} { set total 0 } else { set total [getary [expr $row-1],6] } set sum [expr $in - $out] set ary($row,6) [expr $total + $sum] incr row } } # 5行5列のテーブル table .t -variable ary -rows 101 -cols 8 -height 11 \ -colstretchmode unset -rowstretchmode unset \ -multiline 0 -selectmode extended \ -titlerows 1 -titlecols 1 -selecttitle 1 \ -browsecommand {change_cell %s} \ -xscrollcommand {.x set} -yscrollcommand {.y set} scrollbar .x -command {.t xview} -orient horizontal scrollbar .y -command {.t yview} -orient vertical grid .t .y -sticky news grid .x -sticky news grid rowconfigure . 0 -weight 1 grid columnconfigure . 0 -weight 1 # Excel風のbindings bind Table <Tab> {::tk::table::MoveCell %W 0 1} bind Table <Return> {::tk::table::MoveCell %W 1 0} bind Table <Control-b> {%W icursor [expr {[%W icursor]-1}]} bind Table <Control-f> {%W icursor [expr {[%W icursor]+1}]} # セルのanchor .t tag config active -anchor w .t tag config e -anchor e .t tag config w -anchor w # タイトルの作成 .t tag config title -relief groove -fg black -bg [.t cget -bg] .t tag config active -fg black set i 1 foreach item {日付 曜日 摘要 収入 支出 差引残高 備考} { set ary(0,$i) $item incr i } for {set i 1} {$i < 101} {incr i} { for {set j 0} {$j < 8} {incr j} { if {$j == 0 && $i > 0} { set ary($i,$j) $i } else { if {$j == 4 || $j == 5 || $j == 6} { .t tag cell e $i,$j } else { .t tag cell w $i,$j } } } } # colのサイズ設定 .t width 0 3 1 10 2 4 3 20 4 8 5 8 6 8 |
タグの機能を使って、列によって右寄せ/左寄せを変更しました。
